Stovaris presents
Ricoh fi-8170
- compact and reliable Front-Office scanner!
Compact and reliable front office scanner that supports a wide range of scanning needs
Type: desktop (USB), network (ethernet)
Scanning speed: 70 ppm. / 140 ppm.
Optical resolution: 600 DPI
Deluxe version: includes software PaperStream® Capture Pro
Are you already a Ricoh customer?
If you are already a Ricoh customer, you can order supplies from Stovaris, the brand's Polish distributor.
Write
Write to your Stovaris sales representative and ask for more information!
Call
Call for a quote: +48 691 701 175,
9:00am-5:00pm Monday through Friday.
Compact size, big possibilities
The fi-8170 scanner provides fast and reliable color scanning, and with an estimated daily scanning volume of 10,000 sheets, it can work hard without taking up valuable space. Automatic separation control ensures smooth business operation, and multiple-feed detection minimizes jams. The manual feed mode can read copy forms, stickered documents, A3 documents folded in half and booklets up to 7mm thick.
10,000 sheets per day
Ensure smooth business operations and express document archiving!
Efficiency and development!
Do you want your scanner to run smoothly and not generate problems? You've come to the right place!
Get the whole picture
Eliminate the need to rescan documents with Overscan Control. Three sensors accurately detect the tip of the document and automatically enlarge the scanning area to provide complete, high-quality images, even when the document is skewed. Combined with Clear Image Capture, you get high-quality images for data extraction. PaperStream software provides additional image management.
Overscan control
Automatic enhancement of the scan image.
Clear Image Capture
High-quality images to download the data.
Meet a variety of scanning needs
Perfectly suited for the front or home office, the fi-8170 scanner provides high-volume, high-speed scanning in a compact size. The high-capacity tray reduces preparation time, ensuring accurate scanning so you can work faster and worry-free.
Easy operation with intuitive features
A color LCD panel allows users to intuitively operate the scanner to change modes, view notifications and select jobs. Stacker Supporter keeps documents of all sizes together, even when scanning mixed batches containing small pieces of paper. It offers USB and LAN connectivity, and the software PaperStream NX Manager allows scanning without a computer or a running web application.
Overscan control
Automatic enhancement of the scan image.
NX Manager
Scanning without a computer or web application turned on.
Software to support end-to-end productivity
Fi series scanners come with scanner driver PaperStream IP and PaperStream Capture software, which increases productivity by reducing the number of pre- and post-scanning operations. Frequent manual operations, such as deleting blank pages, can be reduced using the Setup Assistant in PaperStream Capture. Extract information from the Machine Readable Zone (MRZ) for efficient entry of customer information from passports and ID cards.
PaperStream IP
Increase productivity by minimizing the number of operations.
Extracting MRZ information
To efficiently enter customer information from passports and ID cards.
Compliance with government and environmental regulations
TAA (Trade Agreements Act) and EPEAT Silver ratings meet federal government compliance standards, giving organizations confidence that the scanner meets all regulatory requirements. EnergyStar® and RoHS ratings provide assurance that the fi-8170 scanner meets an organization's sustainability requirements as we work together to protect our environment for future generations.
Overscan control
Automatic enhancement of the scan image.
NX Manager
Scanning without a computer or web application turned on.
General specifications
Scanner type -. ADF (automatic document feeder) / Manual feeding, Duplexing
Simplex / Duplex -. Duplex
Scanning speed (color/gray scale/monochrome) -. Single-sided: 70 ppm (200/300 dpi); Duplex: 140 images/min (200/300 dpi).
Image sensor - CIS x 2 (front x 1, rear x 1)
Light source - RGB LED x 2 (front x 1, back x 1)
Optical resolution - 600 dpi
Output resolution (color/gray scale/monochrome) -. 50 to 600 dpi (adjustable in 1 dpi increments), 1200 dpi (driver)
Output format -. Color: 24-bit, grayscale: 8-bit, monochrome: 1-bit
Background colors - White/black (your choice)
Dimensions (W x D x H) -. 300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in)
Weight - 4 kg (8.8 lbs)
Supported operating system - Windows® 11, Windows® 10, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, macOS*17, Linux (Ubuntu)
Image processing functions - Multi-image output, auto color detection, blank page detection, dynamic threshold (iDTC), advanced DTC, SDTC, error spreading, dithering, raster removal, highlighting, color removal (none/red/green/blue/white/saturation/non-standard), sRGB output, hole removal, index tab clipping, split image, diagonal removal, edge fill, vertical streak reduction, background pattern removal, clipping, static threshold
Features of the document
Document size -. Min: 48 x 50 mm (1.9 x 2 inches); Max: 215.9 x 355.6 mm (8.5 x 14 in; Long page scanning: 6096 mm (240 inches)
Paper weight (thickness): Paper: 20 to 465 g/m² (5.3 to 124 lb); Brochure: Less than 7 mm (0.276 in.); Plastic card: 1.4 mm (0.055 inch) or less
ADF capacity - 100 sheets (A4 80 gsm or Letter 20 lb)
Expected daily volume - 10,000 sheets
Multiple feed detection - Overlap detection (ultrasonic sensor), length detection
Paper protection - Image monitoring, sound detection (iSOP) background pattern, clipping, static threshold
Connectivity
USB - USB 3.2 Gen1x1 / USB 2.0 / USB 1.1
Ethernet - 10BASE-T, 100BASE-TX, 1000BASE-T
Power requirements
Power requirements - AC 100 V - 240 V 50/60 Hz
Operating mode -. 28 W or less / 17 W (Eco mode)
Sleep mode -. LAN: 2.0 watts or less USB: 1.4 watts or less
Auto standby (off) mode -. 0.2 W or less
Environmental data - Temperature 5 to 35 °C (41 to 95 °F)
Relative humidity - 15 to 80% (non-condensing)
Environmental compliance - ENERGY STAR®, RoHS
Software to support end-to-end productivity
When you order a fi-8170 scanner from Stovaris, you not only have the chance to significantly improve efficiency and productivity in your workplace, thanks to its integration with PaperStream software , which automates processes for extremely efficient work.
When you choose Stovaris, however, you gain much more than the equipment itself. You get a comprehensive service, including professional advice on selecting the perfect equipment for your needs, fast and reliable delivery, and technical support in case of any problems. You save time and money by avoiding the hassle of buying and integrating the equipment yourself. Stovaris is a guarantee of quality, reliability and customer satisfaction. Unlike buying on your own, where you face numerous challenges, from choosing the right model to configuration and possible technical support, Stovaris offers a complete "A to Z" solution, giving you peace of mind and confidence that your investment in a fi-8170 scanner will bring tangible benefits.
